Schweitzer Engineering SEL-3355-2 - Introduction; Procedure Overview; Unpack and Setup

Date Code 20180212 Getting Started With the SEL-3355-2
3
Introduction
The SEL-3355-2 is a rack-mountable rugged computer. It is designed to operate in extreme environments and
carries the Schweitzer Engineering Laboratories ten-year worldwide warranty. The SEL-3355-2 has the following
features:
➤ Intel
®
Xeon E3 processor
➤ Four 2.5" SATA drive bay with hot-swap and RAID capabilities
➤ Six USB 3.1 ports
➤ Five PCI expansion card slots
➤ Two Gigabit Ethernet interfaces
➤ Dual, redundant power supplies with hot-swap
➤ Watchdog timer for automatic recovery from system lockup
➤ Three display interfaces supporting three simultaneous independent displays
➤ HD Audio inputs and output
Procedure Overview
The following is a list of the primary tasks described in this guide:
➤ Unpack and Setup on page 3
➤ First Boot on page 8
➤ Install Expansion Cards on page 12
➤ Install Operating System on page 13
➤ Install Applications on page 14
➤ Create a Backup With SEL BaRT on page 14
➤ Long-Term Storage on page 15
Unpack and Setup
Verify that the correct number and type of power supplies are installed (see Figure 1 and Figure 2).
Figure 1 Single Power Supply
Figure 2 Dual Power Supplies
