Handling, Servicing & Maint.
Pilot's Flight Manual
Reissued: 16 Jan 2019 7-19
Tail Ro tor Con trol Pedal: (If he li cop ter is equipped with a
one-piece chin skin, re move side panel; if equipped with a
three piece chin skin re move ap pro pri ate chin skin to gain
ac cess.) Un der cabin floor, lo cate and press re lease but tons
of quick-dis con nect pins in left and right pedal sock ets and
re move pins. Re move left and right pedal from re spec tive
sock ets and from rub ber boots that are at tached to cabin
floor. Us ing plugs pro vided with the dual con trol kit, plug
the rub ber boots to pre vent ex haust fumes from en ter ing
cabin.
Cal cu late weight and bal ance in ac cor dance with Sec tion 6
and the air craft equip ment list.
2. In stal la tion of dual con trols.
Col lec tive Con trol: Gently ro tate throt tle con trol han dle as
the col lec tive stick is in serted into the col lec tive con trol
socket. Fully seat con trol stick in socket and ro tate at tach -
ment lug into re ten tion slots. In stall quick-dis con nect pin.
Ro tate throt tle con trol and ob serve pi lots col lec tive throt tle
con trol han dle for cor re spond ing ac tion and ob serve that
throt tle arm reaches full open and full closed stops at the
car bu re tor.
Cy clic Con trol
: In sert cy clic con trol stick into cy clic con -
trol socket. Align holes in cy clic stick with holes in socket
and in stall quick-dis con nect pin; OR in stall knob as sem bly
and safety pin. Route cy clic con trol wire bun dle in a man -
ner that will not in ter fere with cy clic move ment and at tach
wire con nec tor. Ro tate lock on con nec tor to se cure con nec -
tion.
Tail Ro tor Con trol Pedal
: Re move ex haust fume plugs from
rub ber boots. In sert left and right tail ro tor con trols into re -
spec tive rub ber boots and sock ets. Align holes in pedal
con trols with holes in pedal sock ets and in stall quick-dis -
con nect pins in sock ets. Ad just ped als as nec es sary to pre -
vent re stric tions in pedal move ment. (In stall fu se lage side
panel or ap pro pri ate chin skin, if ap pli ca ble.)
Cal cu late weight and bal ance in ac cor dance with Sec tion 6
and the air craft equip ment list.
SCHWEIZER
Model 269C-1 Helicopter
CSP book 2..indd 157 8/4/19 12:54 PM
