Figure 6-5. Sample Weight and Balance Report (Sheet 2 of 2)
Weight and Balance
Pilot's Flight Manual
Schweizer RSG, LLC.
Model 269D Helicopter
6-10
Reissued: 16 Jan 2019
WEIGHT AND C.G. CALCULATIONS
WEIGHT
(LBS)
LONG.
ARM (IN.)
LONG.
MOMENT
(IN.-LB.)
LAT. ARM
(IN.)
LAT.
MOMENT
(IN.-LB.)
Total Unadjusted Net Weight 1148 105.5 121107 + .46 + 531
Total Weight Of Missing Equipment 8.4 97.0 +815 +24.4 +205
Total Weight of Surplus Equipment - 8 65 -520 - 7 + 56
Total Delivered Weight 1148 105.8 121402 + .69 + 792
EXAMPLE OF LOADING TOWARDS FORWARD C.G.
WEIGHT
(LBS)
LONG.
ARM (IN.)
LONG.
MOMENT
(IN.-LB.)
LAT. ARM
(IN.)
LAT.
MOMENT
(IN.-LB.)
Total Delivery Weight 1148 105.8 121402 + .69 +792
Right Seat 170 68.6 11662 + 23.75 + 4038
Center Seat 170 78.6 13362 + 1.25 + 213
Left Seat 170 68.6 11662 - 21.50 - 3655
Fuel Quantity 100 104.2 10420 + 17.0 + 1700
Gross Weight 1758 95.8 168508 + 1.76 + 3088
EXAMPLE OF LOADING TOWARDS AFT C.G.
WEIGHT
(LBS)
LONG.
ARM (IN.)
LONG.
MOMENT
(IN.-LB.)
LAT. ARM
(IN.)
LAT.
MOMENT
(IN.-LB.)
Total Delivery Weight 1148 105.8 121402 + .69 + 792
Right Seat 140 68.6 9604 + 23.75 + 3325
Center Seat NONE ----
Left Seat 120 68.6 8232 - 21.50 - 2580
Fuel Quantity 390 104.2 40638 + 4.4 + 1716
Gross Weight 1798 100.0 179876 + 1.81 + 3253
