Table 7-3. Access and Inspection Provisions Information (cont)
Door/Panel Description Provides Access To
Instrument console side panel
- LH/RH
Instrument console components and
wiring
Collective stick access panel
- LH
Collective stick gear housing - left
side
Engine access panel - Lower Engine - lower
Engine access panel - LH Engine - left side, N
2
controls
Engine access panel - RH Engine - right side, starter/generator,
N
1
controls.
Tower assembly panel - LH Flight controls, swashplate
Tower assembly panel - RH Flight controls, swashplate, ELT if
installed.
Main access door - LH Electrical components/wiring, belt
drive transmission, main transmis-
sion, battery, fuel lines, oil lines, en-
gine oil tank/sight gauge
Main access door - RH Belt drive transmission, main trans-
mission/dipstick, fuel lines, oil lines,
flight controls, generator control unit,
oil filter
Aft access door Wiring, battery cable/battery relay
(optional location), internal plenum
inlet screen
Aft access panel Tail rotor drive shaft/damper, strobe
power supply, battery (optional loca-
tion)
Stabilizer access panel NAV-anticollision light wiring,
attachment hardware.
Forward access panel Electrical components and wiring
Handling, Servicing & Maint.
Pilot's Flight Manual
Schweizer RSG, LLC.
Model 269D Helicopter
7-34
Reiss
ued: 16 Jan 2019
