Upper Vertical Stabilizer-
Portion Above Boom Centerline:
Span 49.0 in.
Sweep 21°
Root Chord 18.0 truncated to 13.0 in.
Area 624.79 in.
2
(Flat area)
Airfoil Root NACA 64
3
A018
Incidence 2° (L. E. Left)
Lower Vertical Stabilizer-
Portion Below Boom Centerline
Span 27.0 in.
Sweep 25°
Root Chord 18.0 truncated to 13.0 in.
Area 256.11 in.
2
(Flat area)
Airfoil Root NACA 64
3
A018
Incidence 2° (L. E. Left)
General
Schweizer RSG, LLC.
Model 269D Helicopter
Pilot's Flight Manual
1-11
Reissued: 16 Jan 2019
