To reduce the risk of electrical shock or unsupervised usage of the equipment, always
unplug the power cord from the wall outlet and wait 5 minutes before cleaning, main-
taining or repairing this machine. Place the power cord in a secure location.
Note: Yourmachinemaynotmatchtheimagesprovidedexactly.
1. Unplug the AC Adapter from the wall outlet and machine.
2. FlextheedgesoftheFrontLowerShroudtodisengage
the 8 inside tabs from the Main Shrouds.
Note: It may be easier to pry up the edges of the Front
LowerShroudusingaatheadscrewdriver.To
avoid damage to the surface of the Shrouds,
we recommend putting a piece of cloth over the
screwdriver blade.
Front Shroud
