Recommended Tools and Lubes
Tools
1. Torque wrench w/ 8mm Allen Key socket: used to tighten the
crank bolts of crank arms to 480 lbf/in.
2. Pedal wrench: Has 15mm and 9/16” wrench to tighten and loosen
pedals.
3. Crank puller: needed to take off right and left crank arms.
4. ISIS Insert Plug for Crank Puller, M12 x 1.0
5. Bottom bracket tool for ISIS Overdrive BB. used to take out bottom
bracket from frame.
6. Adjustable wrench: used to tighten or loosen the pop pin
assembly from frame.
7. 17mm wrench: used to adjust the inside axle nuts closest to the
flywheel bearings.
8. 15mm wrench: used to loosen the outside axle nut on each side
of the flywheel bearings.
9. 14mm wrench: used to tighten the nuts of the seat bracket.
10. 13mm wrench: needed during assembly for the front and back
stabilizers nuts and bolts.
11. 11mm wrench: used to tighten the larger bolt of the brake
assembly.
12. 10mm wrench: used to adjust chain tensioner bolts during chain
tightening, transport wheel nut and bolt and front nut of the
resistance assembly when centering brake pads.
13. 8mm wrench: goes to the smaller resistance knob nylon nut
(older models) and smaller brake assembly bolt.
14. 7mm wrench: used to loosen guide rod nut when replacing
guide rod springs.
15. 5mm Allen wrench: used to tighten the bolts on Evolution
stabilizers.
16. 4mm Allen wrench: used to loosen the bolt of the brake pads
and the Allen chain guard screws (newer models).
17. 3mm Allen wrench: used for the screws of the water bottle
cages.
18. Smart Release™ adjusting tool: high quality tool specifically
designed for use with the new adjustable Smart Release™
mechanism. (SR Models only).
Lubes
1. Schwinn
®
Fit-Tech Silicone Spray: recommended for the
brake pads and all moving parts (e.g., handle bar post, seat
post & slide, pop-pins, resistance knob etc.)
2. Schwinn
®
Equipment Polish: recommended on a damp cloth
when wiping down the frame after use.
3. Schwinn
®
Citrus Chain Wax: recommend to lubricate
the chain through the rear hole in the chain guard as the
flywheel is rotating.
4. Schwinn
®
Quick Shot: recommended for the threads of
stabilizer bolts and pedals before tightening to crank arms.
We recommend the following tools and lubes to properly assemble, maintain and repair all Schwinn
®
Indoor Cycling bikes.
Service Manual
5
