11
n Moving your Schwinn IC Bike
Make sure that the handlebar is securely attached to the bike and that the
pop pin has been turned clockwise until tight. Standing in front of the bike,
grasp the handlebars at their very ends. Place one foot on the lower stabilizer
bar and tilt the bike towards you. Once the bike has tilted enough to engage
the transport wheel, you will be able to easily roll the bike in any direction. Be
gentle while moving the bike as any sudden impact may affect the operation
of the machine.
n Leveling the unit
The Schwinn IC Bike can be leveled to compensate for uneven surfaces. To
level the bike, raise or lower the four leveling bolts located on the underside of
the legs using an adjustable wrench (Fig 10.).
FIG.9
FIG.10
