43
A
E
C
F
B
A
D
B
D
G
3. Remove the hardware that attaches the Chain Guard Cover
to the Chain Guard Inside, and set it safely aside for reassembly.
Carefully remove the Chain Guard Cover and set it safely aside for
reassembly.
4. Mark the position of the Flywheel Retainer Clips (A) on the
flywheel brackets (B) on the Frame. Record the number of threads
showing on the Hex Head Bolt (C) that attaches each Flywheel
Retainer Clip to the Frame.
X4
X2
