Schwinn Rascal Plus - Attach Corner Flaps; Extend Tow Bar

EXTEND THE TOW BAR
TIP! To perform this step turn the trailer so the back side is at to
the ground, and the front end if facing up.
❶ Remove the loop from the end of the locking pin, then remove
the locking pin from the tow bracket. Figure 3.8
ATTACH THE CORNER FLAPS
❶ Fold the corner aps (located on each corner) over and fasten
with the hook and loop fasteners.
❷ Unroll the zippered bug screen and zip closed. Leave the
weather shield rolled up into the elastic bands. Figure 3.7
7 Schwinn Rascal Plus Pet Trailer
Figure 3.8
1
1
1
Figure 3.7
2
