Schwinn Rascal Plus - Attach Axle

ATTACH THE AXLE
TIP! To perform turn the trailer upside down so the boom frame
is facing up.
❶ Align the holes in the rear axle with the holes in the boom of
the trailer frame. Figure 3.10
❷ Holding the end of the tow bar, li the tow bar and rotate the
bar up and over unl the tow bar is fully extended into the
tow posion.
❸ Re-insert the locking pin through the tow bracket, and lock it
by inserting the end of the loop onto the end of the locking
pin. Figure 3.9
Schwinn Rascal Plus Pet Trailer 8
Figure 3.9
2
3
1
Tow posion
Figure 3.10
