Schwinn Rascal Plus - Assembly; Remove Crossbar Bracket

• There are pinch points between the sidewalls and the frame
of the trailer that may cause injury. Fold or unfold the trailer
slowly using cauon.
• Keep children clear when folding or unfolding the trailer.
• Ensure that all locking devices are engaged before use.
❶ Cut the ziptie holding the axle to the frame. Keep the axle
close-by as you will need it for the frame assembly. Figure 3.1
3 Assembly
WARNING!
REMOVE THE CROSSBAR BRACKET
IMPORTANT! Before unfolding the frame, remove the crossbar
bracket from the end of the crossbar.
❷ Press the tab on the crossbar and remove the latch from
the end of the crossbar.
❸ Using a 4 mm hex wrench, remove the bolt from the end of
the bracket. Keep the bracket and the bolt close-by as you
will need them for the frame assembly. Figure 3.2
Schwinn Rascal Plus Pet Trailer 4
Figure 3.1
3
2
2
1
Figure 3.2
