❷ Remove the caps from the ends of the axles.
❸ Insert the axle of each wheel into the holes located on the
sides of the axle frame. Figure 3.14
ATTACH THE WHEELS
❶ Remove the loops from the ends of each locking pin, then
remove the locking pins from each side of the axle. Figure 3.13
Schwinn Rascal Plus Pet Trailer 10
Figure 3.13 Figure 3.14
Wheels that are not securely locked in place may fall o the
trailer and cause serious injury or death. Always check the
wheels are securely locked in place before use.
WARNING!
1
1
2
3
