26
Ref. Description Ref. Description
79 Hex Nut 5/16”-18NC (12.7BX6.75H) 108 Power Cord
80 Hex Head Bolt 5/16”-18NCX1-3/4” 109 V-Belt A36
81 Linkage 110 Motor Pulley
82 Swivel Block 111 Hex head Bolt 5/16”-18NCX3/4”
83 Hex Nut 5/8”-18NF (23.81BX8H) 112 Flat Washer 8.5X23X2.0T
84 Spacer 113 Motor 1HPX110/220VX60HZX1PHX2P
85 Hex Nut 3/8”-16NC (14.2BX8.33H) 114 Lock Washer 8.2X15.4
86 Screw 115 Flat Washer 4.3X10X1.0T
87 Link Plate 116 Phillips Screw 1/8”-40NCX3/8”
88 Fence Slide Block 117 Motor Wire SJT16AWGX3CX700MM
89 Hex Head Bolt 5/16”-18NCX1” 118 Switch Assembly
90 Plate 118-1 Switch Pad
91 Flat Washer 6.6X13X1.0T 118-2 Switch Front Cover
92 Phillips Screw 1/4”-20NCX1/2” 118-3 Switch Body
93 Pulley Cover 118-4 Switch Back Cover
96 Push Block Storage Bracket 118-5 Phillips Screw M4X0.7PX25
97 Push Block 119 Knife Setting Gauge Block
100 Knob 120 E Ring ETW-9
101 Door Latch 121 Knife Gauge Bar
102 Hex Nut 3/8”-16NC(14.2BX8.33H) 124 Key 5x5x30
103 Dust Port 125 Allen Key 3mm
104 Flange Bolt 3/8”-16NCX3/4” 126 Open Wrench 8-10mm
105 Stand 127 Open Wrench 12-14mm
106 Door 128 Knife Setting Gauge Assembly
107 Cord Retainer SB7R-1 129 Spring
