SCORPION J075 - Unpacking; List of Contents; Additional Tools Required

Carefully unpack and remove the jointer and its components from the box and check for damaged or miss-
ing items as per the list of contents below. Report any damaged or missing items to your CWI distributor
immediately.
List of Contents Quantity
J075 and J100
A- Jointer bed ............................................................1
B- Motor ............................................................1
C- Cutter head guard ....................................................1
D- Fence lock handle....................................................1
E- V belt ............................................................ 1
F- Handwheel ........................................................... 2
G- Fence ............................................................1
H- Fence tilt lever ........................................................1
I- Push block ........................................................... 2
J- Flange bolt & lock washer ....................................... 3
K- Wrench and allen key ............................................. 4
L*- Knife setting gauge .................................................1
J075 Only
M- Pulley guard stud, at washer, hex nut....................1
N- Motor mounting bracket ...........................................1
O- Long carriage bolt, washer, hex nut........................ 4
P- Dust port mounting bracket ......................................1
Q- Pulley guard ........................................................... 3
R- Dust port ............................................................ 1
S- Stand upper brace .................................................. 4
T- On/O󰀨 Switch ...........................................................1
U- Pan head phillips screw, at washer ....................... 4
V- Stand leg, rubber feet.............................................. 4
W- Short carriage bolt, washer, hex nut .................... 42
X- Small phillips screw, at washer ............................. 4
Y- Stand lower brace ................................................... 4
Z- Push pad storage bracket ....................................... 2
AA- Wing screw ........................................................... 2
J100 Only
BB- Closed base .........................................................1
CC- Base door ............................................................1
DD- Small phillips screw, at washer .......................... 4
EE- Pulley guard...........................................................1
FF- Phillips screw, at washer ..................................... 8
GG- Dust port ........................................................... 8
*HSS knife models only
Additional Tools Required
In addition to the tools supplied with the jointer, you will need the following tools during assembly and setup:
• Phillips Head Screwdriver
• Machinist’s Square
• Straight Edge
• A Friend to Help Lift
