EH222 E and Condensing Unit
Remote Low Side Cuber User Manual
June 2017
Page 11
Lower Light and Switch Panel
This user accessible panel provides important
operational information and duplicates the lights
and switches on the controller. It also allows
access to the On and Off buttons that operate
the ice machine.
Sometimes access to the switches should be limited
to prevent unauthorized operation. For that
purpose a xed panel is shipped in the hardware
package. The xed panel cannot be opened.
To install the xed panel:
1. Remove the front panel and remove the bezel.
2. Spread the bezel frame open and remove
original door, insert xed panel into bezel. Be
sure it is in the closed position.
3. Return bezel to panel and install panel on unit.
Open door to access
On and Off switch
buttons.
Lower Light and Switch Panel
