Scotsman Prodigy Plus E Series - Cabinet Drawings, Ice Making Head

EH222 E and Condensing Unit
Remote Low Side Cuber User Manual
June 2017
Page 5
Cabinet Drawings, Ice Making Head
22.00
558.80
22.70
576.68
29.00
736.60
TOP VIEW
REAR VIEW
6.00
152.40
3.25
82.55
3.19
80.97 10.75
MINIMUM BIN
TOP OPENING
273.05
19.00
482.60
8.31
211.09
46.24
1.82
82.55
3.25
74.72
2.94
260.80
10.27
A
LINE SET, POTABLE WATER INLET 3/8",
120V AC, AND INTERFACE CABLE
SEE DETAIL "A"
ULTRA SONIC
BIN LEVEL
SENSOR
ICE DROP AREA
15.00
381
16.41
416.92
16.72
424.70
DRAIN 3/4" PVC FEMALE REAR, LEFT AND RIGHT SIDE ACCESS
LEFT SIDE VIEW
24
.95
42.80
1.69
79.38
3.13
115.95
4.57
68.20
2.69
131.70
5.19
24.89
.98
34.04
1.34
67.56
2.66
34.04
1.34
DETAIL A
INTERFACE CABLE
ACCESS HOLE
3/4" SUCTION LINE
POTABLE WATER INLET 3/8"
1/2" COOL VAPOR LINE
3/8" LIQUID LINE
ELECTRICAL CORD
ACCESS HOLE
EH222
ICE HEAD
