GENIUS LT
32 2011 SCOTT BIKE OWNERS MANUAL
GENIUS LT
33
ENGLISH
It is also possible to use 180mm rotors. To do so, please remove the 2 washers with a
laser logo of “185mm” and fix the calliper directly on the PM on the seatstay.
In case you want to use a rotor with 203mm please use an adapter offered by the
manufacturer of the brake system of your choice.
This adaptor needs to be assembled between PM and the calliper.
Important:
Please note that it is not possible to use other rotor dimensions than those shown in
the text above!
IDS 2 / REPLACEABLE DROPOUT
All Genius LT bikes feature the new IDS 2 System of Scott.
3 different version of IDS 2 are available,
- RWS 12/142
- RWS 12/135
- RWS 5/135
They all can only be used in combination with the DT Swiss RWS skewer/axle.
Axle Skewer
