SCOTT SCALE CARBON User Manual

SCALE CARBON
2 2011 SCOTT BIKE OWNERS MANUAL
SCALE CARBON
3
CONTENT
The Scale Carbon bikes should be adjusted exactly to the
current rider for reaching maximum safety and fun while
riding.
All adjustments should be done at the local Scott dealer
or following to this manual.
Scale Carbon Concept P. 004
Geometry Scale P. 005
Technical Data Scale P. 006
BB Standards/ FD Mounting Details P. 006
Chainguide P. 008
Headset Options P. 009
BB Cable Guide/Cable Routing P. 010
Seattube Clamp P. 012
Replaceable Rear Derailleur Hanger P. 013
Rear Disc Brake Mount P. 014
Front Fork Set-Up/Change of Front Fork P. 015
Warranty P. 016
ENGLISH
H_scale_carbon_en.indd 2-3 19.04.10 11:04

SCOTT SCALE CARBON Specifications

General

Frame Material	Carbon
Wheel Size	29"
Wheelset	Syncros (depending on the specific model)
Saddle	Syncros (depending on the specific model)
Fork	RockShox / FOX / Suntour (depending on the specific model)
Drivetrain	Shimano or SRAM (depending on the specific model)
Brakes	Shimano or SRAM disc brakes (depending on the specific model)
Tires	Schwalbe or Maxxis (depending on the specific model)
Handlebar	Syncros Alloy or Carbon (depending on the specific model)
Seatpost	Syncros Alloy or Carbon (depending on the specific model)
