SCS Compact - Operating instructions
Overview SCS Compact
The exterior view of the coffee machine
The inside view of the coffee machine
1. Bean hopper for 1 or 2 grinders
2. 2 Powder hoppers
3. Slot for max. 16 grams of decaffeinated coffee
powder / slot for cleaning tablet
4. Display for 4 to 12 products
5. Door lock integrated in the front door
6. Drinks outlet (height adjustable)
7. Hot water outlet
8. Cup positioner (optional)
9. Drip grid
10. Drip tray
1. Powder hopper left
2. Powder hopper right
3. Powder module
4. Front door
5. Water tank (optional)
6. Door lock integrated in the front door
7. Grounds drawer
8. Main switch
Instant module
1. Powder hopper 1 (for soluble food only)
2. Powder hopper 2 (for soluble food only)
3. Powder slide left
4. Powder slide right
5. Mixer cup ring
6. Mixer cup
7. Mixer cup interlock
1.
2.
3.
5.
4.
6.
7.
10.
9.
8.
2.
1.
4.
3.
6.
5.
8.
7.
2.
1.
3.
6.
5.
7.
4.
