SCS Compact - Technical Data and Installation

- 60 -
SCS Compact - Operating instructions
Technical Data
Models SCS Compact
Type
Weight
(with 1 grinder)
Tea water
litre / h
Instant Milk
Electrical
connection
CTI 37 kg up to 15 yes - A
MCTI 40 kg up to 15 yes yes A, B
C Coffee
T Hot water / Tea water
M Milk
I Instant with 2 powder containers
A 1N 230 VAC 2.2 kW
B 2N 400 VAC 3.8 kW
Add-on units
Add-on unit Capacity Weight Electrical connection
L/Ld Refrigerator SCS Compact (on the left side) 4 litres 14 kg 1N 230VAC 0.070kW
Lb/Lbd Refrigerator with black tray (left side) 4 litres 18 kg 1N 230VAC 0.070kW
Lt/Ltd Refrigerator with transparent tray (left side) 4 litres 18 kg 1N 230VAC 0.070kW
Ls/Lsd Refrigerator with self-service deck 4 litres 18 kg 1N 230VAC 0.070kW
Lv Refrigerator with cup warmer 4 liters / 40 cups 21 kg 1N 230VAC 0.150kW
W Cup warmer SCS Compact up to 80 cups 13 kg 1N 230VAC 0.150kW
CD Cup dispenser SCS Compact up to 200 cups 12 kg - - -
CC Coin changer (on the right side only) - - - 15 kg - - -
CA Coin acceptor - - - 4 kg - - -
Water supply / drain
Component Specication
Water supply G3/8“, L = 1500 mm
Water pressure 200 - 600 kPa (2-6 bar)
Water hardness 5 -8 dH° / 8 - 14 fH°
Chlorine content max. 0.1 mg/Liter
Drain ø = 16 mm, L = 2000 mm
Siphon ø = 48 mm
