Scuba Force SF2 ECCR - Page 25

Manual Version 19 / 01-2019 II Page 25 of 44
SF2 ECCR OPERATION MANUAL
The oxygen sensors are
simply brought into position
The sensor holder plate has three
holes. These must be positioned
correctly so that the screws fit.
The screws are hand-
tightened.
The sensor cables are
plugged onto the sensors. The
length of the cable determines
which cable goes to which
sensor.
