2. Description
Air filter cover fasteners
“Low temperatures” position
Spark arrester fixing screw
Exhaust silencer protection
3. Preparation before use
3.1. Positioning the generating set for operation
Choose a site that is clean, well ventilated and sheltered from bad weather.
Place the generating set on a flat, horizontal surface which is firm enough to prevent the set sinking down (under no circumstances
should the set tilt in any direction by more than 10°).
Store the additional supplies of oil and fuel within close proximity, whilst maintaining a certain distance for safety.
3.2. Earthing the generating set
The generating sets supply electrical current when in operation: risk of electrocution.
Connect the generating set to the ground at each use.
To connect the set to the ground: Attach a 10 mm
2
copper wire to the set‟s earth connection and to a galvanised steel earthing rod
driven 1 meter into the ground.
3.3. Checking the oil level
Before starting the generating set, always check the engine oil level.
Top up with the recommended oil (see § Characteristics) using a funnel, up to the top limit of the gauge.
Remove the oil filler gauge plug (fig. A - No. 2 & fig. B - No. 2) by unscrewing it, and wipe the gauge.
Insert the oil filler gauge plug into the filler neck (fig. B - No. 3) without screwing it, then remove it.
Visually check the level and top up if necessary.
Screw the oil filler gauge plug back fully into the filler neck.
Wipe off excess oil with a clean cloth, check that there are no leaks.
