SE Electronics RNT - Technical Specifications (RNT)

6
Technical Specifications (RNT)
Capsule
Hand-crafted 1" diaphragm true condenser capsule
Polar patterns
9 (omni, cardioid, figure-8 with three additional steps between each)
Tube complement
1x 12AU7 (ECC82)
Frequency range
20 – 20,000 Hz
Sensitivity
16 mV/Pa (-36 dBV)
Gain
-12 / 0 / +12 dB, switchable
Max. SPL (0.5% THD)
151 dB
SPL
Equivalent noise level
18 dB(A)
Dynamic range
133 dB
Signal-to-noise ratio
76 dB
Low cut filter
40 / 80 Hz, 12 dB/Oct, switchable
Electrical impedance (floor box output)
30 Ohms
Recommended load impedance
>2k Ohms
Connectivity
3-pin male XLR connector
Power requirement
Floor Box / PSU (included)
Dimensions
Microphone
Diameter 62 mm (2.44 in.) Length 240 mm (9.45 in.)
Floor Box / PSU
356 x 135 x 100 mm (14.02 x 5.31 x 3.94 in.)
Weight
Microphone
989 g (34.90 oz.)
Floor Box / PSU
3905 g (137.79 oz.)
