SE Electronics RNT - Technical Specifications (RNR1)

8
Figure-8
Technical Specifications (RNR1)
Acoustic operating principle
Electrodynamic pressure gradient with active electronics
Transducer
Hand-tensioned 2.5µm aluminum ribbon
Polar pattern
Figure-8
Frequency range
20 Hz – 20 kHz
Sensitivity
25 mV/Pa (-32 dB)
Max. SPL (0.5% THD @1kHz)
137 dB
SPL
Signal to noise ratio
77 dB
Self noise
17 dB(A)
Low cut filter switch
100 Hz
Power requirements
+48V phantom power
Electrical Impedance
200 Ohms
Matching Connectors
XLR3F
Dimensions
47mm (diameter) x 268mm (height)
Weight
860g / 30.34oz
Frequency response Polar Pattern
