SE Electronics sE7 - Technical Specifications

3
Controls
The sE7 / sE7 sideFire features a switch for the attenuation pad and a switch for the low-cut filter.
Attenuation Switch
The Attenuation Switch is located on the upper rear side of the
microphone. When switched on, the incoming signal is reduced by 20 dB
for the capture of loud instruments and/or close-miking without
distortion. Using the switch also helps prevent overloading the input
stage of recording interfaces, mixing desks and microphone preamps.
Low-Cut Switch
The Low-Cut Switch is located on the lower rear side of the microphone
and inserts a low-cut filter at 80Hz. The switch’s top position removes
the filter for a flat frequency response. Wind noise, plosives, footfall
noise or rumble might affect the recorded signal, so enabling the low-cut
filter reduces such unwanted noise and prevents distortion. Additionally,
the low-cut filter also minimizes the proximity effect when recording
sound sources at a very short distance.
Technical specifications
Capsule
1/2“ back-electret condenser capsule
Polar patterns
Cardioid
Frequency range
20 – 20,000 Hz
Sensitivity
19 mV/Pa (-34.5 dBV)
Max. SPL (0.5% THD)
136 / 156 dB
SPL
(0/20 dB Attenuation pad)
Equivalent noise level
16 dB(A)
Dynamic range
120 / 140 dB (0/20 dB Attenuation pad)
Signal-to-noise ratio
78 dB
Low cut filter
80 Hz, 6 dB/Oct, switchable
Attenuation pad
20 dB, switchable
Powering
48 Volts according to IEC 61938
Electrical impedance
<200 Ohms
Recommended load impedance
>1k Ohms
Current consumption
3.0 mA
Connectivity
3-pin male XLR connector
Dimensions
sE7: ø 23 mm (0.91 in.) x L 120 mm (4.72 in.)
sE7 sideFire: ø 23 mm (0.91 in.) x L 130 mm (5.12 in.)
Weight
sE7: 128 g (4.52 oz.)
sE7 sideFire: 163g (5.75 oz.)
