MAINTENANCE PROCEDURES
Engine Coolant Replacement
Coolant replacement should be per-
formed by an authorized Sea-Doo
dealer.
Ignition Coils
Ignition Coil Removal
1. Open seat.
2. Remove engine cover (as applicable
to model).
3. Disconnect ignition coil connector.
NOTICE
Do not remove the igni-
tion coil before disconnecting the
input connector or the wires may be
damaged. Do not pry up ignition coil
with a screwdriver to avoid damage.
NOTE: Twist ignition coil in both direc-
tions as you pull it up to e ase removal.
Remove ignition coil from spark plug.
Ignition Coil Lubrication
1. Pull rubber seal down.
sbs2009-011-002_a
1. Rubber seal pulled down
2. Apply DOW CORNING 111 (P/N 413
707 000) to rubber seal seat as
shown.
sbs2009-011-001_a
1. Apply product here
3. Pull rubber seal back on its seat
making sure the tabs on the ignition
coil and the slots in the seal properly
match together.
4. Leave a ring of grease on top of the
seal as shown to act as a water bar-
rier. Wipe off the excess.
sbs2009-011-003_a
1. Correctly shaped excess of product
5. Apply DOW CORNING 111 (P/N 413
707 000) on rubber seal contact
area.
smr05-015-002_d
1. Apply product here
112
