EQUIPMENT
smo2011-003-014_a
1. Boarding platform
2. Spotter foot rests (each side)
7) Front and Rear Eyelets
Eyelets can be used for mooring , tow-
ing a water skier, wakeboarder or tu-
ber, and as tie-down points w he n trai-
lering your watercraft.
Front Eyelet
smo2008-001-020_a
TYPICAL
1. Front eyelet
Rear Eyelets
smo2009-002-132_b
TYPICAL
1. Rear eyelets
All M odels Except WA KE
smo2011-003-026_a
1. Rear eyelet
8) Bilge Drain Plugs
Unscrew drain plugs whenever wa-
tercraft is on the trailer. This will allow
water accumulated in the bilge to be
evacuated and helps to reduce con-
densation.
smo2009-002-135_a
TYPICAL
1. Drain plugs
2. Tighten
3. Loosen
_______________
69
