SINGLE LEVEL MFG BILL OF MATERIAL
FIND QTY PART NO REV DESCRIPTION REFERENCE DESIGNATOR
1 1 EA 116286-5 B OMT, DUAL BAND, 4-PORT
2 2 EA 110256-2 WAVEGUIDE FILTER, WR-229, 3.7-4.2GHz
3 2 EA 114540 B1 LNB, C-BAND
4 1 EA 123648-1 D SCALAR PLATE ASS'Y, C/KU-BAND, RX ONL
5 1 EA 132463-1 B LNBF, QUAD, KU, INVERTO, MODIFIED
6 1 EA 113648-1 K FEED ADAPTER PLATE
9 1 EA 111576-2 E BRACKET, FEED COUNTERWEIGHT, 16 IN
10 2 EA 112573-2 C WEIGHT, TRIM, 1/2 x 2.75 x 3, 1.17 LB
12 2 EA 114586-542 SCREW, HEX HD, 1/4-20 x 1-3/4, S.S.
13 3 EA 114586-556 SCREW, HEX HD, 1/4-20 x 7/8, S.S.
15 4 EA 114580-029 WASHER, FLAT, 1/4, S.S.
16 37 EA 114581-029 WASHER, LOCK, 1/4, S.S
17 38 EA 114583-029 NUT, HEX, 1/4-20, S.S.
18 4 EA 114576-146 SCREW, FLAT HD, PHIL, 6-32 x 3/8 S.S.
19 3 EA 114590-189 SCREW, SOCKET SET-CUP, 8-32 x 3/16, S
20 37 EA 114586-538 SCREW, HEX HD, 1/4-20 x 1, S.S.
30 1 EA 116686 A1 STOP, MECHANICAL
33 76 EA 114580-027 WASHER, FLAT, 1/4, SMALL PATTERN, S.S
34 3 EA 114586-537 SCREW, HEX HD, 1/4-20 x 3/4, S.S.
2SHT 1 OF
FEED ASS'Y, DUAL C/QUAD KU, DISHSCAN
PROD FAMILY
COMMON
EFF. DATE
8/18/2010
DRAWING
NUMBER
125425-1
REV D
