SEA KITE - Technical Specifications

10
7. Motor
8. Metallic bever gear
9. Bearings
10. Endless-screw
11. Lead screw barrel nut
1. Aluminium casing
2. Front fixing bracket
3. Back fixing bracket
4. Release system
5. Terminal board
6. Capacitor
KITE , is an irreversible electromechanical swing gate operator strong and safe, easy to install, for leaf length
up to 5 m is equipped with release system through key, which allows the manual release of . KITE operator
the leaf in case of emergency or black out
ENGLISH
International registered trademark n. 804888
TECHNICAL SPECIFICATIONS
USING GRAPHICS
TECHNICAL DATA
Power supply
Max. Power
Max. Absorbed current
Stroke
Speed
Cycle/hour
(operating at 20°C)
Operating temperature
Anti-crushing Clutch
Max. thrust
Operator weight
Protection Class
Max. Leaf length
Max. Leaf weight
Fig. 1
1
2
3
4
5
7
9
9
10
1
1
6
8
DIMENSIONS (mm)
Fig. 2
1003
930
78
* 370 mm with magnetic limit switch
Note: The frequency of use is valid only for the first hour
at 20°C room temperature
500
Kg
5 m4 m3 m2 m1 m
400
300
200
100
Weight
Leaf length
5 m
50
MAX LEAF LENGTH
OPERATOR
CYCLES/HOUR
24Vcc 36Vcc
60 W 260 W
2,5 A 1 A
400 mm *
ADJUSTABLE (MAX. 16") ADJUSTABLEE (MAX. 15")
50
-20°C +55°C
ELECTRONIC
1800 N 3000 N
7,8 Kg
Ip 44
5 m
500 Kg
KITE 500 H 24V
KITE 500 H BR 36V
KITE 500 H 24V
KITE 500 H 24V
KITE 500 H BR 36V
KITE 500 H BR 36V
