SEA KITE - Installation on Masonry Pillars; Connections; Wiring Terminal Layout; Connection Safety Precaution

13
Fig. 10
a
d
b
60
155 Min.
1300
60
155 Min.
d
During installation, make
sure that the connection
cables do not interfere
with the recess
CAUTION!
200
80 Min.
NOTES
CONNECTIONS
operator
1 - dimensions in mm
2 - In case you need to
make a recess, observe
the shown dimensions
INSTALLATION ON MASONRY PILLARS, MAKING A RECESS
Terminal
board
ENGLISH
International registered trademark n. 804888
make connections only after installation is complete and when the power supply is OFF
Fig. 11
24V MOTOR
24V MOTOR
KITE 500 24V
Fig. 12
CLOSING LIMIT SWITCH (BROWN)
OPENING LIMIT SWITCH (WHITE)
COMMON LIMIT SWITCH
(WHITE/BROWN)
KITE 500 BR 36V
Fig. 13
U
V
GROUND
W
CLOSING LIMIT SWITCH (BROWN)
OPENING LIMIT SWITCH (WHITE)
COMMON (-) LIMIT SWITCH
(WHITE/BROWN)
