DOCS-010 Manual, SeaBotix Inc. Users, 200 Series – 18 Mar 09 - Rev B - Page 27 of 52
2.3.4.3 Depth
a. Pressing the 3 key will allow you to calibrate the depth information on the
Video Overlay.
Note: The operator should only set depth to zero on the surface before each
deployment. Use of other depth functions during deployment could offset the
depth indication.
To adjust the depth value:
Press key 1 to increase the value
Press key 2 to decrease the value
Press key 3 to set to zero
Press key 4 to reset to the default
Press key 5 to set the slope
2.3.4.4 Compass
a. Pressing the 4 key will allow you to calibrate the compass heading
information on the Video Overlay.
To calibrate the compass, refer to section 1.8 “Compass Calibration” for more
information.
2.3.4.5 Monitor
a. This function does not apply to Fiber Optic Video equipped systems.
Pressing the 5 key will allow you to adjust the RF gain on the monitor on the
LBV150BE and LBV150S systems.
2.3.5 System
2.3.5.1 Thruster Motors
Pressing the 1 key will take you to the thruster motors diagnostic menu. From there you can
check the status of each thruster on the LBV.
1. Port
2. Starboard
3. Lateral
4. Vertical
5. TBD
2.3.5.2 Software Version
a. Pressing the 2 key will allow you to view the current software versions.
This information is important when technical assistance is required.
CC – Operator Control Unit (OCU)
ROV – Flash in LBV (Operational Program)
