Seagate Nytro 2.5” x 7mm SSD Product Manual, Rev. A 10
Scope
www.seagate.com
NOTE More information on Vibration:
Operating vibration: The drive, as installed for normal operation, shall
operate error free while subjected to specified vibration not exceeding
specification. Vibration may be applied in the X, Y, or Z-axis.
NOTE M
ore information on Airflow:
It is recommended that airflow for 2.5-inch form factor should be towards
the server, from the non-connector side to the connector side. Airflow is
specified across the surface of the drive. Spacing all sides is assumed to be
3mm.
1.8 Reliability
Table 12 Reliability
Specification Reliability Data
Mean Time Between Failures (MTBF)
2 million hours
Data Retention 3 months @ 40°C
Non-recoverable Read Errors per bits read
1 per 10E16
NOTE Here is more information on Reliability:
MTBF specification is based on these assumptions for Enterprise Storage
System environments: 8760 power on hours per year, 250 power on/off
cycles per year, and nominal voltages. The drive achieves specified MTBF
when operating in an environment that ensures the case temperatures do
not exceed the temperature specifications.
Data Retention is the time that NAND retains data at maximum rated
endurance
Table 10 Vibration
Specification Vibration
Vibration - Profile Operating 3.08 G
RMS
(7-800Hz), 16.3 G
RMS
(20-2000Hz)
Table 11 Airflow Requirements
Airflow Definition Unit
Ambient
Temperature
Airflow
Airflow Along Drive LFM
35
°C
412
