Seagate Nytro 5000 - Mechanical Information; Dimensions and Weight

Seagate Nytro 2.5” x 7mm SSD Product Manual, Rev. A 12
Mechanical Information
www.seagate.com
2.0 Mechanical Information
2.1 Mechanical Dimensions and Weight - 2.5” Models
Weight: 2.5” models 0.198 pounds 90 grams
Figure 1. Configuration dimensions (2.5” models)
NOTE These dimensions conform to the Small Form Factor Standard documented in
SFF-8200 and SFF-8639. The latest revisions may be found at
www.sffcommittee.org.
2.2 Bottom Cover Stiffness/Deflection
Operating: No uncorrectable errors
10mm probe: 1.02kgf or 5mm probe: 0.92kgf
Non-Operating: No uncorrectable errors
20mm probe: 2.0kgf on any point on bottom cover
Table 15 Bottom Cover Stiffness/Deflection
