7
INSTALL THE AILERONS
CONTROL HORN
Fiberglass control horn
3.
2.
1.
4.
6.
7.
5.
Epoxy
Epoxy
Ailerons control horn
Check the t of the aileron to the wing.
e top of the ailerons will align to the
top of the wing. Make sure movement is
smooth and bind free.
We prefer 30-minute epoxy to allow
enough working time during the hinge
installation.
