SEAKEEPER 26 GYRO
90265
2
2 of 12
Section 2: ELECTRICAL INSTALLATION
2.1 Electrical Equipment Mounting
Precautions
• Each item of electrical equipment has specific mounting instructions. These instructions should
be followed to insure proper function of the SEAKEEPER 26 Gyro.
1. COLOR DISPLAY MOUNTING INSTRUCTIONS, SURFACE MOUNT
a. Console space required: Approx. 4.57 W x 4.57 H inches (116 x 116 mm)
b. Mounting Instructions, Surface Mount: See drawing 90337 for details
2. SERIAL COMMUNICATIONS TEE ADAPTER AND TERMINATOR MOUNTING INSTRUCTIONS
a. Console space required, Rear: Approx. 4 W x 3 H inches (102 x 76 mm), rear
b. Mounting Instructions: Rear mount on vessel console panel, within 1 ft (0.3m) of
Display.
c. Hardware required: One mounting screw for .197” (5 mm) diameter mounting hole on
Tee Adapter.
Do NOT move Gyro mounted components from their
locations or incorrect Gyro operation will result.
