INSTALLATION
MANUAL
Section 5: INSTALLATION CHECKLIST AND SUPPLIES
Please Complete Checklist and E-mail to customerservice@seakeeper.com
or telefax to +1.410.326.1199
5.0 Installation Checklist
Mechanical Checklist (reference Installation Manual Section 1)
Gyro Foundation Installed in Hull
Foundation bolts torqued to specification
Electrical Checklist (reference Seakeeper Drawing 90310 & Installation Manual Section 2)
Mount Components
Display (near helm)
Connect Customer Supplied Cables
Cable 1 – Connect Cable 1 to 24 VDC power at customer
supplied connection box or directly to circuit
breaker
– Plug connector of Cable 1 into mating connector
on gyro wire harness
Cable 6 (customer supplied) – Install lugs on both ends of customer supplied
4AWG ground cable
– Connect one end of Cable 6 to nearest vessel
ground and other end to gyro rear brace
Connect Seakeeper Supplied Cables
Cable 2 (Seakeeper supplied) – Connect Cable 2 from Drive Box to 230 VAC single
phase at customer supplied connection box or
directly to circuit breaker
Cable 5 (Seakeeper supplied) – Connect Cable 5 from Drive Box to customer
supplied 230 VAC seawater pump
Cable 3 (Seakeeper supplied) – Connect female end of CAN communications
Cable 3 to mating connector on gyro wire harness
