Section 5: INSTALLATION CHECKLIST AND SUPPLIES
 – Route CAN communications Cable 3 from gyro to
helm (male end goes to helm)
 – Connect male end of CAN communications Cable 3
at helm to CAN Tee Adapter
 – Connect Display and Seakeeper supplied Cable 4
to CAN Tee Adapter with CAN Terminator
Cooling Checklist (reference Installation Manual Section 3)
 Verify coolant level in heat exchanger coolant reservoir.
 Connect sea water hoses / open sea cocks to heat exchanger and test sea water
pump.
 Verify 4 GPM (15 LPM) minimum and 8 GPM (30 LPM) maximum sea water flow
through heat exchanger under all operating conditions of the boat.
Startup Checklist (reference Installation Manual Section 4 and Operation Manual Section 2)
 Remove lifting bolts and replace with sealing screw/washers provided, Install cover
panels
 Turn on 24 VDC circuit breaker
 Turn on 230 VAC circuit breaker
 Verify display works and no alarms are present
 Follow instructions in Section 4.1 of Installation Manual to turn on the GYRO
 Verify sea water pump turns on when the GYRO is turned ON
 Verify that no ALARMS are present
 Follow instruction in Section 4.1 of Installation Manual to turn off the Gyro
 AC & DC power and sea water pump may be turned off after the GYRO is turned off
by placing the GYRO in LOCK mode and Turning the GYRO off
 Gyro takes 6+ hours to coast down to zero rpm from full speed
