Seakeeper 3 - Seakeeper Specifications; Seakeeper 3 Specifications and Summary


OPERATION
MANUAL
Product: Document #: Rev: Page:
SEAKEEPER 3 90379 1 1 of 3
Section 6: SEAKEEPER SPECIFICATIONS


Seakeeper 3 Specifications & Summary
Seakeeper 3
Rated RPM
8,450 RPM
Angular Momentum at Rated RPM
3,000 N-M-S
Anti-Rolling Torque at Rated RPM
7,854 N-M
Spool-up Time to Rated Speed
50 minutes (8,450 RPM)
Spool-up Time to Stabilization
36 minutes (7,185 RPM)
Spool-up Power
DC Motor 900 Watts Max
Operating Power
DC (Sea state dependent) 400-750 Watts
Voltage
DC Input
12 VDC @ 85 Amps
Seawater Supply to Heat
Exchanger
22 LPM (6 GPM) maximum
8 LPM (2 GPM) minimum
Ambient Air Temperature
0˚ - 60˚C (32˚ - 140˚F)
Weight
249 kg. (550 lbs)
Envelope Dimensions
0.68 L x 0.69 W x 0.572 H (meters)
26.8 L x 27.0 W x 22.5 H (inches)
Noise Output
At full operating RPM, steady state noise measured in the
factory at a 1 meter distance measures 64-66 dBC (sound
levels may be higher during spool-up).
