Section 1: SYSTEM OVERVIEW


1.3 Drive Box
The glycol/water mix that cools the Seakeeper is also circulated through a cold plate inside the
Drive Box to remove heat from high-power electronic components.
The Motor Drive Box contains an electrical hazard and the
cover should not be removed while the flywheel is spinning
and the DC input voltage is present. The electrical hazard
exists even if the flywheel is coasting down and the supply
voltage has been shut off. The flywheel must be at Zero (0)
RPM and DC input power disconnected for at least 10 minutes
prior to any service work on the motor drive box.
FIGURE 5 – DRIVE BOX

