Sealy Ease - Quick Reference Guide; Control Box Overview; Electronics Overview

5
quick reference guide
Not to scale. For illustration purposes only. Read all instructions before beginning installation.
Power Cord
Power Supply
Battery Backup Box
Wireless
Remote
Head Motor Foot Motor
Control Box
ELECTRONICS OVERVIEWCONTROL BOX OVERVIEW
Input
Power Cord
To remove Control Box, release
metal clip and unplug cords.
If installing a split unit, see pages 12–13.
Input Cord
Connection
Power
LED Light
Port Button Head Motor
Port
Foot Motor
Port
