FT430/440/450 INSTRUCTIONS
Seametrics • 253.872.0284 Page 11 seametrics.com
CONNECTION DIAGRAMS
FT4XX Sensus Tranceiver Connections
FT4XX Eqipped with Sensus Board (Side View)
Sensus Tranceiver
Red (Power/Clock)
Black (Ground)
Green (Data)
Red
Black
Green
NOTE: A Sensus 2m (6 ft) output cable is prewired to the
Seametrics product at the factory. Longer cables are optional.
