Seastar Solutions i7700 User Manual

DUAL STATION/DUAL ENGINETRIPLE STATION/DUAL ENGINE
1. Control Head
2. Throttle/Shift Actuator
3. CAN Network Bus
1
2 3
1
2222 3
1
1
1 1
3
SINGLE STATION/SINGLE ENGINE
Figure 2-1. System Overview.
© 2017 SeaStar Solutions i7700 Shift & Throttle System User’s Manual, Rev. A
2-2
2.2 System Overview Diagram
