© 2017 SeaStar Solutions i7700 Shift & Throttle System User’s Manual, Rev. A
3-8
SHIFT
DETENT
THROTTLE
FRICTION
Figure 3-7.
Lever Adjustment
The control lever feel can be adjusted by means of adjusting screws
on the forward face of the control head.
• The friction drag on the lever is adjusted with the throttle friction
adjuster screw (see figure 3-4 or figure 3-7). Turn the screw clockwise
to increase the friction on the lever, counter-clockwise to reduce
the friction.
•
The force required to move in and out of the shift detents is adjusted
with the Shift Detent adjuster screw. The detents are meant to prevent
accidental gear engagement, so bear that in mind as you make
adjustments. Clockwise increases force, counter-clockwise decreases.
3.3.3
Figure 3-8. Control Head lever positions.
Adjusting
Screws
