© 2012 SeaStar Solutions Optimus Operations Manual, Rev. D
3-5
3.2 Initial Start Up
ON MULTIPLE HELM STATION BOATS ALL STEERING HELMS ARE ACTIVE
WHEN THE OPTIMUS EPS IS TURNED ON. THIS IS THE SAME AS YOU
WOULD FIND ON A CONVENTIONAL HYDRAULIC STEERING SYSTEM.
Turning on the ignition switch will turn on the Optimus EPS system.
The CANtrak Display will turn on and steering will become active at
all helms.
After reading the initial warning screen press the INFO button and
follow the prompts for a system inspection.
All Helms Active
Splash Screen
Initial Warning System Check 1 System Check 2
INFO NEXT
3 SEC INTERVAL
BACK
OK
System Check 3
NEXT
OK
BACK
WARNING
Figure 3-9. All Helms Active screen (normal steering mode).
Figure 3-8. CANtrak initial warning screen.
