© 2012 SeaStar Solutions Optimus Operations Manual, Rev. D
8-1
8.0 TROUBLESHOOTING GUIDE
WHENEVER, IN THE FOLLOWING TEXT, A SOLUTION CALLS FOR
REMOVAL FROM VESSEL AND/OR DISMANTLING OF STEERING
SYSTEM COMPONENTS, SUCH WORK MUST ONLY BE CARRIED
OUT BY A QUALIFIED MARINE HYDRAULIC MECHANIC. SEASTAR
SOLUTIONS OFFERS THE FOLLOWING AS A GUIDE ONLY AND IS
NOT RESPONSIBLE FOR ANY CONSEQUENCES RESULTING FROM
INCORRECT DISMANTLING REPAIRS.
Optimus EPS steering will provide years of safe reliable performance
with a minimum of service if properly installed.
Optimus steering systems have been designed with protection against
over-pressure situations, with the inclusion of a pressure relief valve
and circuit breakers, to minimize the possibility of total loss of steering.
Most faults occur when the installation instructions are not followed
and usually show up immediately upon filling the system. Listed below
are the most common faults encountered and their likely cause
and solution.
FAULT CAUSE
SOLUTION
Check circuit breaker for the engine. Reset breaker. If it immediately trips
a second time look for a shorted or
pinched wire or failed component.
3. One engine does
not steer, but
CANtrak display is
on.
Batteries not turned ON, or in poor
working condition.
Ignition wires disconnected.
CANtrak connection damaged and/
or not connected.
Load test batteries.
Confirm all connections are in place.
Inspect wires for damage.
1. CANtrak does not
turn ON?
Tachometer is not relaying
information.
CANtrak NOT writing proper
information.
Confirm Tachometer is operating
properly (check connections).
Confirm that your settings have
been saved. If they are not saved,
contact Tech support.
2. High/Low Speed
wheel turn setting
not working
WARNING
