© 2012 SeaStar Solutions Optimus Operations Manual, Rev. D
6-7
6.2.4 System Fault Handling – Example
The following is an example of how the system would respond to the
warning fault hazard of a communication loss.
The CANtrak display will enter the warning screen mode and pulse
the system warning buzzer. The three warning screen zones will
appear as shown below.
Active Fault
Description Zone
Fault Handling
Instructions Zone
System Status Zone
This area shows the
active faults
Tells the User how
to proceed
Describes what system has
done to react to fault
Figure 6-6. Sample warning fault.
