SECOLink LAN800 - System Template Details; Zone Configuration; PGM Output Configuration

THE TEMPLATE (continued)
PGM OUTPUTS
Output -PGM (1):
address 00_2 (-PGM(1) terminal on CP);
pre-set name: “Siren Trigger”;
PGM definition: Fire / Burglary Alarm;
alarm time: 5 minutes;
attributes: (+) Pulse;
Trigger: All violated zones and tampers of modules;
Comment: intended to be used as a power&trigger for low power
siren (buzzer) or as a trigger for the back-up siren .
Output +PGM (2):
address 00_3 (+PGM(2) terminal on CP);
pre-set name: “Smoke detect.PWR”;
PGM definition: Fire Power Supply;
reset time: 10 sec.;
reset triggered: by zone 5 violation;
Comment: intended to be used as a power supply for smoke detectors.
Short programming manual - basic information
Intruder alarm system
System with KM20B, KM20BT keypads
ZONES
1st system zone:
address 00_1 (Z1 terminal on CP);
assigned to partition:1;
pre-set name: “Entry Door”;
zone definition: Entry/Exit;
loop (detector) type: NC;
zone speed (sensitivity): 0,4 sec.;
entry delay: 30 sec.;
attributes: (+) Bypass Enabled, (+) Limit alarms,
(+) Limit reports;
comment: intended to be used with a
magnetic door contact.
2nd system zone:
address 00_2 (Z2 terminal on CP);
assigned to partition:1;
pre-set name: “Hallway”;
zone definition: Follower;
loop (detector) type: NC;
zone speed (sensitivity): 0,4 sec.;
attributes: (+) Entry route, (+) Exit route,
(+) Bypass Enabled, (+) Limit alarms, (+) Limit
reports;
Comment: intended to be used with PIR
detector.
3rd system zone:
address 00_3 (Z3 terminal on CP);
assigned to partition:1;
pre-set name: “Kitchen”;
zone definition: Interior;
loop (detector) type: NC;
zone speed (sensitivity): 0,4 sec.;
attributes: (+) Bypass Enabled, (+) Limit alarms,
(+) Limit reports;
Comment: intended to be used with PIR
detector.
5th system zone:
address 00_5 (Z5 terminal on CP);
assigned to partition:1;
pre-set name: “Smoke detector”;
zone definition: 24h smoke;
loop (detector) type: NO;
zone speed (sensitivity): 0,4 sec.;
attributes: (+) Fire Verification, Limit alarms,
(+) Limit reports,(+) Bypass Enabled;
Comment: intended to be used with smoke
detector. Attribute indicates that detector
power supply must be +PGM(2).
8th system zone:
address 01_2 (Z2 terminal on keypad);
other settings same as for the 2nd zone.
Output +BELL:
address 00_1 (+BELL terminal on CP);
pre-set name: “Siren +PWR”;
PGM definition: Fire / Burglary Alarm;
alarm time: 5 minutes;
attributes: (+) Pulse;
trigger: All violated zones and tampers of modules;
Comment: intended to be used as a power&trigger for non back-up
siren. For the back-up siren +BELL definition should be changed to
Power Supply and alarm trigger should be provided by -PGM (1).
4th system zone:
address 00_4 (Z4 terminal on CP);
pre-set name: “Bedroom”;
other settings same as for the 3rd zone.
7th system zone:
address 01_1 (Z1 terminal on keypad);
other settings same as for the 1st zone.
REPORTING
Reporting via PSTN:
reporting: Off;
telephone line monitoring: Off;
dial tone test: Off;
dial method: Tone;
dial attempts in 1 session: 4;
number of sessions: 3;
pause between sessions: 1 min.;
line missing time for PSTN line trouble detection: 1 min..
Reporting via Radio/GSM/GPRS transmitters:
Reporting: Off.
Time settings for Periodic Test reporting:
days: 0 (0 = disabled);
time: 00:00.
Control Panel:
pre-set name: “Control Panel”;
assigned to partition: 1;
module tamper (terminal Z6): On;
entry delay for Entry/Exit zone: On**;
modules monitoring: On**;
arming during the exit delay regardless of zone violation : Off**;
detection of not wired PGM (PGM uses no power): Off**;
+BELL auto shutdown when back-up battery is discharged: On**;
-PGM(1) auto shutdown when back-up battery is discharged: On**;
+PGM(2) auto shutdown when back-up battery is discharged: On**.
Keypad
pre-set name: “LCD Keypad”;
assigned to partition: 1;
module tamper: Off;
emergency keys:
Fire alarm: On*;
Medical alarm: On*;
Panic alarm (audible): On*.
MODULES
6th system zone:
address 00_6 (tamper switch on CP);
If the tamper function is needless it
can be turned OFF, and zone:
address 00_6 (Z6 terminal on CP);
will serve as usual zone.
Page 3
