THE TEMPLATE (continued)
Short programming manual - basic information
Intruder alarm system
System with KM20B, KM20BT keypads
GLOBAL TIME SETTINGS
alarm time on keypad : 10 sec.;
exit delay: 30 sec.;
auto arm delay: 30 sec.;
pre-alarm time: 10 sec.;
Arm/Disarm notification time for PGM output: 0,5 sec.**;
smoke detector settle time: 5 sec.;
fire zone verification time:15 sec.;
Reporting delay on Entry zone alarm: 30 sec.*;
AC missing time for AC loss detection: 3 min.;
reporting and alarm shutdown when zone is triggered more than: 7 times**;
reset alarms counter for each zone: every 9h**.
SECOLINK SYSTEM ELEMENTS TO BE PROGRAMMED
(Follow the steps)
user name: 1st user;
status: Active (enabled);
default PIN: 0001;
user rights: all rights are turned On;
user name: Service ;
status: Active (enabled);
default PIN: 0000.
USERS
users: 2-3, 4-15, 16-31;
status: Inactive (disabled);
default PIN: 0002-0031;
user rights: all rights are turned On;
Page 4
PGM name [up to 16 symbols]
PGM address [MA_P]
MA is module address, P is PGM
terminal on module PCB
PGM definition [20 definitions]
Fire/Burglary Alarm, Burglary Alarm,
Tamper Alarm, ...
PGM attributes [5 attributes]
Pulse on fire, Pre-alarm, Latch, ...
Triggering Source 1
Zones, partitions, timers, trouble
types**, alarm types**
Triggering Source 2
Modules, partitions, trouble types**
PGM OUTPUTS (4th step)
Zone name [up to 16 symbols]
Zone address [MA_Z]
MA is module address, Z is zone
terminal on module PCB
Zone loop type [7 types]
NO, NC, NC/EOL, NC/DEOL, ...
Zone definition [21 definitions]
Entry/Exit, Interior, Perimeter, ...
Zone speed [0,4-2,5 sec.]
Zone attributes [9 attributes]
Bypass enabled, No alarm zone (for
temperature zone only), ...
Entry delay [1-255 sec.]
For Entry/Exit only
ZONES (3rd step)
Module name [up to 16 symbols]
Module address [1-7 or 1-15]
Belongs to partition [1-4]
Use module tamper [Yes/No]
Module specific settings:
Emergency keys for the keypad, settings for the proximity card reader PROX8, ...*
MODULES (2nd step)
Number of partitions [1-4]
Partition name [up to 16 symbols]
Exit delay for each partition: [1-255 sec.,for PAS832 only]*
Entry delay [On/Off]**
Arming by timer in STAY mode [1-4-8-16 timers]
Pre-alarm by timer [1-16 timers, for PAS832 only]**
Common partition (corridor) [On/Off]**
PARTITIONS (1st step)
Reporting via PSTN
Phone numbers, client account,
number of attempts in dialing session,
dialing method (tone/pulse), PSTN line
monitoring, ...
REPORTING SETTINGS (5th step)
Reporting via GSM/GPRS, RF
Client account
Alarm time on keypad: [1-255 sec.]
Exit delay for all partitions (except PAS832): [1-255 sec.]
Smoke detector settle time: [0-255 sec.]
Fire zone verification time: [0-255 sec.]
Immediate reporting on Entry zone alarm: [Yes/No]*
Other global time settings...
GLOBAL TIME SETTINGS (6th step)
Keypad settings:
User interface [4 types]
Simple 1 part., Advanced, Baltic, Asian
Date format
DD/MM/YYYY or YYYY-MM-DD
F-keys [up to 32 F-keys]**
Chime
Other settings:
PIN length, LCD backlight, contrast, ...
RCM800(wl) settings:
Commands: [up to 38 commands]**
MACROS: [up to 8 MACROS]**
PROX8 settings:
Priority sequence for arming modes:
Away/Max Away/Night/Stay ...*
Installation: [Indoor/Outdoor]*
Hide system status: [Yes/No]*
Intruder RFID:*
No action/Indication/Alarm Intruder RFID...*
Managed partitions: [1-4]*
USER INTERFACE (7th step)
User activation:
[Temporary PIN for new user On]
User name [up to 16 symbols]
User rights [13 rights]
Arm, Disarm, Clear alarm, ...
Controlled partitions [1 to 4]
USERS (8th step)
Timer name [up to 16 symbols]
Timer On time
Timer Off time
Scheduler
TIMERS (optional step)
User PIN resetting to default: [Enabled/
Disabled]
Duress code: [Enabled/Disabled]
SECURITY SETTINGS (optional step)
