Sectron EGS5 GPRS JAVA Terminal - Terminal Specifications: BGS5, EHS5, EHS6

7
BGS5 GPRS JAVA Terminal USB, EHS5 HSPA JAVA Terminal, EHS6 JAVA Terminal
RS232 – Connector for terminal connection via RS232
PWR ~ – Power connection terminals 8 – 30 V AC/DC (polarity does not matter)
LED power diode– LED diode that indicates the power status, it lights up green when the device is turned
on
ANT – Antenna for GSM signal reception
SIM – SIM card slot
LED diode SIM – 1:1 – terminal not logged into GSM network
– 1:9 – terminal is registered into GSM
network
USB – USB connector for computer connection
– In the case of the terminal with „USB“ in the name, the terminal can also be powered via the USB
port
Name
BGS5 GPRS Java Terminal
EHS5 HSPA Java Terminal
EHS6 Java Terminal
GSM module
Gemalto M2M GmbH -
Cinterion BGS5
Gemalto M2M GmbH -
Cinterion EHS5
Gemalto M2M GmbH -
Cinterion EHS6
Frequency bands GSM
850/900/1800/1900 MHz
850/900/1800/1900 MHz
850/900/1800/1900 MHz
Communication speed(kbps)
85,6/42,8
85,6/85,6
236,8/236,8
User interface
RS-232, USB
RS-232, USB
RS-232, USB
Operating temperature range
-20
0
C up to +55
0
C
-20
0
C up to +55
0
C
-20
0
C up to +55
0
C
Operating temperature range
-40
0
C up to +85
0
C
-40
0
C up to +85
0
C
-40
0
C up to +85
0
C
Power voltage
8 – 30 V AC/DC, USB
8 – 30 V AC/DC, USB
8 – 30 V AC/DC, USB
Power consumption
1 W / 3.5 W (receive /
transmit)
1 W / 3.5 W (receive / transmit)
1 W / 3.5 W (receive /
transmit)
Antenna connector
SMA(f) 50 Ohm
SMA(f) 50 Ohm
SMA(f) 50 Ohm
Dimensions
25 x 54 x 97 mm
25 x 54 x 97 mm
25 x 54 x 97 mm
Mounting
DIN rail 35 mm
DIN rail 35 mm
DIN rail 35 mm
Weight
105 g
105 g
105 g
